GigE Compact CMOS camera corresponding POE
| Model No. | Monochrome/ Color/Near-IR |
Resolution | Frame Rate | Effective Pixels (H x V, pixels) |
Sensor Size | Cell Size (H x V, μm) |
Sensor | Lens Mount | Shutter Type |
|---|---|---|---|---|---|---|---|---|---|
| STC-MBS43POE | Monochrome | 0.4M | 282fps | 728 x 544 | 1/2.9″ | 6.9 x 6.9 | IMX287 | C Mount | Global |
| STC-MCS43POE | Color | 0.4M | 282fps | 728 x 544 | 1/2.9″ | 6.9 x 6.9 | IMX287 | C Mount | Global |
| STC-MBS52POE | Monochrome | 0.5M | 166.5fps | 812 x 620 | 1/1.7″ | 9.0 x 9.0 | IMX433 | C Mount | Global |
| STC-MCS52POE | Color | 0.5M | 166.5fps | 812 x 620 | 1/1.7″ | 9.0 x 9.0 | IMX433 | C Mount | Global |
| STC-MBE132POE | Monochrome | 1.3M | 61fps | 1280 x 1024 | 1/1.8″ | 5.3 x 5.3 | EV76C560 | C Mount | Global |
| STC-MCE132POE | Color | 1.3M | 61fps | 1280 x 1024 | 1/1.8″ | 5.3 x 5.3 | EV76C560 | C Mount | Global |
| STC-MBS163POE | Monochrome | 1.6M | 70.7fps | 1440 x 1080 | 1/2.9″ | 3.45 x 3.45 | IMX273 | C Mount | Global |
| STC-MCS163POE | Color | 1.6M | 70.7fps | 1440 x 1080 | 1/2.9″ | 3.45 x 3.45 | IMX273 | C Mount | Global |
| STC-MBS202POE | Monochrome | 2M | 54.6fps | 1624 x 1240 | 1/1.7″ | 4.5 x 4.5 | IMX430 | C Mount | Global |
| STC-MCS202POE | Color | 2M | 54.6fps | 1624 x 1240 | 1/1.7″ | 4.5 x 4.5 | IMX430 | C Mount | Global |
| STC-MBS231POE | Monochrome | 2.3M | 41.6fps | 1920 x 1200 | 1/1.2″ | 5.86 x 5.86 | IMX249 | C Mount | Global |
| STC-MCS231POE | Color | 2.3M | 41.6fps | 1920 x 1200 | 1/1.2″ | 5.86 x 5.86 | IMX249 | C Mount | Global |
| STC-MBS312POE | Monochrome | 3.2M | 34.9fps | 2048 x 1536 | 1/1.8″ | 3.45 x 3.45 | IMX265 | C Mount | Global |
| STC-MCS312POE | Color | 3.2M | 34.9fps | 2048 x 1536 | 1/1.8″ | 3.45 x 3.45 | IMX265 | C Mount | Global |
| STC-MBA503POE | Monochrome | 5M | 14fps | 2592 x 1944 | 1/2.5″ | 2.2 x 2.2 | MT9P031 | C Mount | Rolling |
| STC-MCA503POE | Color | 5M | 14fps | 2592 x 1944 | 1/2.5″ | 2.2 x 2.2 | MT9P031 | C Mount | Rolling |
| STC-MBS500POE | Monochrome | 5M | 21.9fps | 2448 x 2048 | 2/3″ | 3.45 x 3.45 | IMX264 | C Mount | Global |
| STC-MCS500POE | Color | 5M | 21.9fps | 2448 x 2048 | 2/3″ | 3.45 x 3.45 | IMX264 | C Mount | Global |
| STC-MBS642POE | Monochrome | 6.4M | 17.4fps | 3072 x 2048 | 1/1.8″ | 2.4 x 2.4 | IMX178 | C Mount | Rolling |
| STC-MCS642POE | Color | 6.4M | 17.4fps | 3072 x 2048 | 1/1.8″ | 2.4 x 2.4 | IMX178 | C Mount | Rolling |
| STC-MBS881POE | Monochrome | 8.9M | 12.4fps | 4096 x 2160 | 1″ | 3.45 x 3.45 | IMX267 | C Mount | Global |
| STC-MCS881POE | Color | 8.9M | 12.4fps | 4096 x 2160 | 1″ | 3.45 x 3.45 | IMX267 | C Mount | Global |
| STC-MBA1002POE | Monochrome | 10M | 10.3fps | 3856 x 2764 | 1/2.3″ | 1.67 x 1.67 | MT9J003 | C Mount | Rolling |
| STC-MBS1242POE | Monochrome | 12M | 9.2fps | 4000 x 3000 | 1/1.7″ | 1.85 x 1.85 | IMX226 | C Mount | Rolling |
| STC-MCS1242POE | Color | 12M | 9.2fps | 4000 x 3000 | 1/1.7″ | 1.85 x 1.85 | IMX226 | C Mount | Rolling |
| STC-MBS122BPOE | Monochrome | 12M | 8.9fps | 4096 x 3000 | 1.1″ | 3.45 x 3.45 | IMX304 | C Mount | Global |
| STC-MCS122BPOE | Color | 12M | 8.9fps | 4096 x 3000 | 1.1″ | 3.45 x 3.45 | IMX304 | C Mount | Global |
| STC-MBS2041POE | Monochrome | 20M | 5.5ps | 5472 x 3648 | 1″ | 2.4 x 2.4 | IMX183 | C Mount | Rolling |
| STC-MCS2041POE | Color | 20M | 5.5ps | 5472 x 3648 | 1″ | 2.4 x 2.4 | IMX183 | C Mount | Rolling |
Monochrome
Color
STC-MBS/MCS881POE
STC-MBS/MCS122BPOE
